Thermische module
Beeldsensor: Vanadiumoxide, ongekoelde focal plane arrays
Resolutie: 640 × 512 (uitvoerresolutie: 1920 × 1080)
Pixelafstand: 17 μm
Golflengtebereik: 8 μm tot 14 μm
NETD: ≤ 35 mK (@25 °C, F# = 1.0)
Brandpuntsafstand: 9 mm
Scherpstelling: Athermalized (temperatuurongevoelig)
IFOV: 1.89 mrad
Diafragma: F1.0
Beeldhoek (H × V): 72.0° × 56.1°
Minimale scherpstelafstand: 1 m
Digitale zoom: ×2, ×4, ×8
Optische module
Beeldsensor: 1/1.8" Progressive Scan CMOS
Resolutie: 2688 × 1520 (4 MP)
Minimale verlichting:
Kleur: 0.005 Lux @ (F1.3, AGC AAN)
Z/W: 0.001 Lux @ (F1.3, AGC AAN)
Beeldhoek: Van 56.6° × 33.7° tot 1.8° × 1.0°
Brandpuntsafstand: 6–240 mm (40× optische zoom)
Diafragma: F1.3–F4.6
Scherpstelling: Auto / Semi-auto / Handmatig
Digitale zoom: ×2, ×4, ×8, ×16
Sluitertijd: 1 s tot 1/30.000 s
WDR: 120 dB
Optische ontmistingsfunctie: Ja
Beeldweergave
Picture-in-Picture: Thermisch beeld in optisch beeld
Doelkleuring: Ondersteund in white hot en black hot
PTZ (Pan-Tilt-Zoom)
Beweging:
Pan: 360° continu
Tilt: -20° tot +90° (auto flip)
Snelheid:
Pan: 0.1°/s tot 200°/s (preset: 240°/s)
Tilt: 0.1°/s tot 105°/s (preset: 200°/s)
Proportionele zoom: Ja
Presets: 300 totaal, 273 configureerbaar
Patrouilles: 8 (max. 32 presets per patrouille)
Patroonherhaling: 4 patronen, elk >10 minuten
Geheugen bij stroomuitval: Ja
Parkacties: Preset, patroon, patrouille, auto scan, tilt scan, random scan, frame scan, panoramische scan
Geplande taken: Inclusief herstart, afstelling, AUX-uitgang
IR-verlichting
Bereik: Tot 200 m
Intensiteit & hoek: Automatisch aangepast
Slimme functies
VCA (Video Content Analyse):
4 regels: lijnoverschrijding, binnendringen, gebied in/uit
Tot 10 scènes, 8 regels per scène
Temperatuurmeting:
3 regeltypes
273 presets, 21 regels per scène (10 punten, 10 gebieden, 1 lijn)
Bereik: -20 °C tot 550 °C
Nauwkeurigheid: Max. (±2 °C, ±2%)
Branddetectie: Dynamisch, tot 10 brandpunten
Video & Audio
Hoofdstream (optisch):
50 Hz: 25 fps (2688×1520, 1920×1080, 1280×960, 1280×720)
60 Hz: 30 fps (idem)
Hoofdstream (thermisch):
50 fps (1920×1080 t/m 384×288)
Substream (optisch):
50 Hz: 25 fps (704×576, 352×288)
60 Hz: 30 fps (idem)
Substream (thermisch):
50 fps (704×576, 640×512, 384×288)
Compressie:
Video: H.265+/H.265/H.264+/H.264
Audio: G.711u/a, G.722.1, MP2L2, G.726, PCM
Netwerk
Protocollen: IPv4/IPv6, HTTP(S), FTP, SMTP, SNMP, RTSP, TCP/UDP, IGMP, DHCP, PPPoE, enz.
Opslag: MicroSD/SDHC/SDXC (tot 256 GB), NAS (NFS, SMB/CIFS), ANR
API: ISAPI, HIKVISION SDK, ONVIF (S, T, G)
Live weergave: Tot 20 kanalen
Gebruikers: Max. 32 (beheerder, operator, gebruiker)
Beveiliging: Wachtwoord, MAC-binding, HTTPS, 802.1x, IP-filtering
Clients: iVMS-4200, Hik-Connect
Browsers:
Plug-in: IE11
Plug-invrij: Chrome 57+, Firefox 52+
Interfaces
Alarm in/uit:
In: 7 kanalen (0–5 VDC)
Uit: 2 relaisuitgangen
Alarmacties: Preset, patrouille, patroon, opname, relais, slimme snapshot, FTP, e-mail
Audio in: 1 × 3.5 mm Mic/Line-in (2–2.4 V [p-p], 1 kΩ ±10%)
Audio uit: Lineair, 600 Ω
Communicatie:
Ethernet: 1 × RJ45 10/100 Mbps
RS-485: 1
Analoge video-uitgang: 1.0 V [p-p]/75 Ω
Algemeen
Talen webclient: 32 talen, incl. Nederlands
Voeding: 24V AC ±20%, 36V DC ±20%, 48V DC ±20%, Hi-PoE
Verbruik: Max. 65 W
Bedrijfstemperatuur: -40 °C tot 65 °C
Luchtvochtigheid: ≤ 95%
Ruitenwisser: Ja
Bescherming: IP66, TVS 6000V (bliksem, overspanning, piekspanning)
Afmetingen: 266.6 × 410 × 198.6 mm
Gewicht: ca. 9 kg
Detectiebereik (VCA)
Mens: 63 m
Voertuig: 189 m
Certificering
EMC: CE-EMC, RCM, IC
Veiligheid: CB, CE-LVD, BIS
Milieu: CE-RoHS, WEEE, REACH
Bescherming: IP66 (IEC 60529-2013)
